Food Vision Using an EffecientNetX and Tensorflow

!nvidia-smi -L

# Show the Tensorflow Version (run this in Google Colab)
import tensorflow as tf
print(tf.__version__)

# Downgrade Tensorflow Version (run this in Google Colab)
!pip install tensorflow==2.4.1

!wget https://raw.githubusercontent.com/realnihal/Random_Code/master/helper_functions.py

from helper_functions import create_tensorboard_callback, plot_loss_curves

#importing tfds
import tensorflow_datasets as tfds

#checking the name of the dataset in present within tfds
datasets_list = tfds.list_builders()
print("food101" in datasets_list)

#Loading the dataset
(train_data, test_data), ds_info = tfds.load(name='food101',
                                             split=['train','validation'],
                                             shuffle_files=True,
                                             as_supervised=True,
                                             with_info=True)

#Features of Food101 from TFDS
ds_info.features

#Printing a few class names
class_names = ds_info.features["label"].names
class_names[:10] #only print 20 to avoid spamming the output

#Lets take one sample to dive deeper and view our data
train_one_sample = train_data.take(1)


#Printing the image features
for image, label in train_one_sample:
  print(f'''
  Image shape: {image.shape}
  Iimage datatype: {image.dtype}
  Target class from Food101 (tensor form): {label}
  Class name (str form): {class_names[label.numpy()]}
  ''')

#Checking whether the image is normalized

tf.reduce_min(image), tf.reduce_max(image)

#Plotting an image from the dataset to check if our labels are correct
import matplotlib.pyplot as plt
plt.imshow(image)
plt.title(class_names[label.numpy()])
plt.axis(False)

# Make a function for preprocessing images
def preprocess_img(image, label, img_shape=224):
  """
  Converts image datatype from 'uint8' -> 'float32' and reshapes image to
  [img_shape, img_shape, color_channels]
  """
  image = tf.image.resize(image, [img_shape, img_shape]) # reshape to img_shape
  #image = image/255.0 (not required)
  return tf.cast(image, tf.float32), label # return (float32_image, label) tuple

#Using our preprocess function to test on the sample image
preprocessed_img = preprocess_img(image, label)[0]
print(f"Image before preprocessing:\n {image[:2]}...,\nShape: {image.shape},\nDatatype: {image.dtype}\n")
print(f"Image after preprocessing:\n {preprocessed_img[:2]}...,\nShape: {preprocessed_img.shape},\nDatatype: {preprocessed_img.dtype}")

# Map preprocessing function to training data (and paralellize)
train_data = train_data.map(map_func=preprocess_img, num_parallel_calls=tf.data.AUTOTUNE)
# Shuffle train_data and turn it into batches and prefetch it (load it faster)
train_data = train_data.shuffle(buffer_size=1000).batch(batch_size=32).prefetch(buffer_size=tf.data.AUTOTUNE)

# Map prepreprocessing function to test data
test_data = test_data.map(preprocess_img, num_parallel_calls=tf.data.AUTOTUNE)
# Turn test data into batches (don't need to shuffle)
test_data = test_data.batch(32).prefetch(tf.data.AUTOTUNE)

train_data, test_data

from tensorflow.keras import mixed_precision
mixed_precision.set_global_policy("mixed_float16")

from tensorflow.keras import layers
from tensorflow.keras.layers.experimental import preprocessing

# Create base model
input_shape = (224, 224, 3)
base_model = tf.keras.applications.EfficientNetB0(include_top=False)
base_model.trainable = False # freeze base model layers

# Create Functional model
inputs = layers.Input(shape=input_shape, name="input_layer")
# x = preprocessing.Rescaling(1./255)(x) EfficientNetBX models have rescaling built-in but if your model didn't you could have a layer like below
x = base_model(inputs, training=False) # set base_model to inference mode only
x = layers.GlobalAveragePooling2D(name="pooling_layer")(x)
x = layers.Dense(len(class_names))(x) # want one output neuron per class
# Separate activation of output layer so we can output float32 activations
outputs = layers.Activation("softmax", dtype=tf.float32, name="softmax_float32")(x)
model = tf.keras.Model(inputs, outputs)

# Compile the model
model.compile(loss="sparse_categorical_crossentropy", # Use sparse_categorical_crossentropy when labels are *not* one-hot
              optimizer=tf.keras.optimizers.Adam(),
              metrics=["accuracy"])

#Printing a summary of the model
model.summary()

#Checking the trainability and datatypes of the layers
for layer in model.layers:
  print(layer.name, layer.trainable, layer.dtype, layer.dtype_policy)

# Create TensorBoard callback (already have "create_tensorboard_callback()" from a previous notebook)
from helper_functions import create_tensorboard_callback

# Create ModelCheckpoint callback to save model's progress
checkpoint_path = "model_checkpoints/cp.ckpt" # saving weights requires ".ckpt" extension
model_checkpoint = tf.keras.callbacks.ModelCheckpoint(checkpoint_path,
                                                      monitor = 'val_accuracy', # save the model weights with best validation accuracy
                                                      save_best_only=True, # only save the best weights
                                                      save_weights_only=True, # only save model weights (not whole model)
                                                      verbose=1)

history_101_food_classes_feature_extract = model.fit(train_data,
                                                     epochs=3,
                                                     steps_per_epoch=len(train_data),
                                                     validation_data=test_data,
                                                     validation_steps=int(0.15 * len(test_data)),
                                                     callbacks=[create_tensorboard_callback("training_logs",
                                                                                            "efficientnetb0_101_classes_all_data_feature_extract"),
                                                                model_checkpoint])

#Evaluating our model on the test data
results_feature_extract_model = model.evaluate(test_data)
results_feature_extract_model

#Saving our model
model.save("101_food_feature_extract_mixedpred_model")

#Loading our model into a seperate model
loaded_model = tf.keras.models.load_model("101_food_feature_extract_mixedpred_model")
loaded_model.load_weights(checkpoint_path)

#Checking if our layer types are accurate in loaded_model
for layer in loaded_model.layers:
  print(layer.name, layer.trainable, layer.dtype, layer.dtype_policy)

#Evaulating on our loaded_model
test_eval = loaded_model.evaluate(test_data)

#Seeing if the results match our actual model.
results_feature_extract_model == test_eval

# Are any of the layers in our model frozen?
for layer in loaded_model.layers:
  layer.trainable = True # set all layers to trainable
  print(layer.name, layer.trainable, layer.dtype, layer.dtype_policy) # make sure loaded model is using mixed precision dtype_policy ("mixed_float16")

# Setup EarlyStopping callback to stop training if model's val_loss doesn't improve for 3 epochs
early_stopping = tf.keras.callbacks.EarlyStopping(monitor="val_loss", # watch the val loss metric
                                                  patience=3) # if val loss decreases for 3 epochs in a row, stop training

# Create ModelCheckpoint callback to save best model during fine-tuning
checkpoint_path = "fine_tune_checkpoints/"
model_checkpoint = tf.keras.callbacks.ModelCheckpoint(checkpoint_path,
                                                      save_best_only=True,
                                                      monitor="val_loss")

reduce_lr = tf.keras.callbacks.ReduceLROnPlateau(monitor="val_loss",
                                                 factor=0.2, # multiply the learning rate by 0.2 (reduce by 5x)
                                                 patience=2,
                                                 verbose=1, # print out when learning rate goes down
                                                 min_lr=1e-7)

loaded_model.compile(loss="sparse_categorical_crossentropy", # sparse_categorical_crossentropy for labels that are *not* one-hot
                        optimizer=tf.keras.optimizers.Adam(0.0001), # 10x lower learning rate than the default
                        metrics=["accuracy"])

history_101_food_classes_all_data_fine_tune = loaded_model.fit(train_data,
                                                        epochs=100, # fine-tune for a maximum of 100 epochs
                                                        steps_per_epoch=len(train_data),
                                                        validation_data=test_data,
                                                        validation_steps=int(0.15 * len(test_data)), # validation during training on 15% of test data
                                                        callbacks=[create_tensorboard_callback("training_logs", "efficientb0_101_classes_all_data_fine_tuning"), # track the model training logs
                                                                   model_checkpoint, # save only the best model during training
                                                                   early_stopping, # stop model after X epochs of no improvements
                                                                   reduce_lr]) # reduce the learning rate after X epochs of no improvements

loaded_model.save("efficientnetb0_fine_tuned_101_classes_mixed_precision")

final_score = loaded_model.evaluate(test_data)

#saving the tensorboard data online - I have multiple models since Iyes tried a couple of ideas
!tensorboard dev upload --logdir ./training_logs \
  --name "Fine-tuning EfficientNetB0 on all Food101 Data" \
  --description "Training results for fine-tuning EfficientNetB0 on Food101 Data with learning rate 0.0001" \
  --one_shot

!zip -r /content/file.zip '101_food_feature_extract_mixedpred_model'

from google.colab import files
files.download("/content/file.zip")

!zip -r /content/file2.zip 'efficientnetb0_fine_tuned_101_classes_mixed_precision'

files.download("/content/file2.zip")
